The SERIES RL3000E Rapid Roll Door

The RL3000 Rapid Roll door has been designed by DMF to suit many applications within the marketplace, including . .

  • Warehouses and docks
  • Pharmaceutical process areas
  • Hospitals
  • Food processing areas
  • Chillers and coolrooms
  • Recycle and waste plants
  • Workshops
  • Carwashes

This high speed door model has been on the market for over 25 years, with design refinements over the years, and operating speeds up to 1.3m/sec. This door is controlled using our unique DMF single phase HMI / PLC control system with the option to suit either a mechanical limit switch settings control (RL3000C) or an encoder limits settings control (RL3000E). Mechanically, these doors are identical.

And now new to DMF is the option of the RL3000Servo control system, a dedicated door controller using state of the art technology servo drive. Almost as easy as “plug n play” this controller is simple to install, plug in cabling, and then easy commissioning.

Various options exist, depending on your selection, including variable speed control, soft start soft stop of door panel, option of battery backup for power loss situations, and many options of activation. These allow you to obtain the optimum performance for your traffic flow, and also traffic movements in the vicinity of the doorway.

The Series RL3000 rapid door componentry design is so simple it can be supplied in a well defined kit form. This can be a major benefit and saving to country and overseas customers by using local technical trades or maintenance persons. To assist, a very comprehensive Installation and Operation Manual comes with the door.

Rapid screen roll doors with ventilation to control vermin entry. Orora Sydney.

Using a  900gsm heavy duty fire retardant Polyskin panel, and efficiently designed columns extrusions, this rapid roll door is ideal for internal or external applications up to 36sq metres – and with special modifications, can accommodate openings to over 7m in width. The control system incorporates our RL3000 digital HMI controller, offering basic programmable features, variable speed control and adjustable hold open timers, and complex 3 way interlocks. This is housed in a plastic IP65 box and features touch screen control, making your rapid roll door easy to program. Common to this range is the optional flexible bottom rail offering greater safety and less impact damage, this option can save a lot of money and downtime. The bottom rail can flex laterally or vertically making it the safest bottom rail on the market. However, it is limited in high air pressure applications or external doorways exposed to high wind.

With the new heavy windbar design, the RL3000 rapid roll door model can tolerate wind speeds of about 70-80km/h depending on the width of the door The Series RL3000 fast action door is custom manufactured to suit any application, and DMF has manufacturing in Sydney, Malaysia and Philippines.

Please have a look at the POLYSKIN COLOUR CHART below for available colours.

Please contact us for details on how these coloured can be mixed and how CLEAR pvc can be incorporated within these coloured panels.

 Go to our GALLERY for great photos of the Series RL3000E Rapid roll doors, in a variety of applications.


Information for ARCHITECTS and DESIGNERS to download.
